| Specification | Description |
|---|---|
| Table Size | 56" Dia |
| Turret Positions | 5 |
| Height Under Rail | 48" |
| Vert Travel of Turret | 30 3/4" |
| Cross Travel of Turret | 38 1/8" |
| Vertical Travel of Side Head | 46 3/4" |
| Cross Travel Side Head | 46 3/4" |
| Drive Motor | 50 HP |
| Approx Weight | 67,000 lbs |
| Size (Approx.) | 180"(LR) x140"(FB) 144"(HT) |
