| Specification | Description |
|---|---|
| Working Surface | 31.5" x 31.5" Pallets |
| X-Axis Travel | 53.1" |
| Y-Axis Travel | 45.2" |
| Z-Axis Travel | 45.2" |
| Max Load on Pallets | 5500 lbs |
| Maximum Spindle Speed | 15,000 RPM |
| Spindle Taper | 50 |
| Spindle Indexing | Full 4th (360,000 degrees) |
| Tool Positions | 120 ATC |
| Spindle Drive Motor | 40 HP High Powered Geared Head |
